- Design Codes: PEB Building - designed following AISC/MBMA in accordance with NBC 2016 & Local Building Regulations.
- Mezzanine: 5% mezzanine for office & storage.
- Clear Height: 12.0 Meter clear height at eaves.
- Column Span/Grid: Grid spacing of 24m x 16m
- Load Considerations: Live load of 0.57 KN/m2 & 0.3KN/m2 Collateral Load for services.
- Roof Type: 0.55 mm Standing seam roof - Bare galvalume. Roof slope up to 1:20
- Ventilation: Ridge ventilation system, to achieve 6 air changes per hour. Z-Type/C-type Louvers on all 4 Sides.
- Natural Light: Poly carbonate sheets equivalent to 4% of roof area on wall cladding.
Industrial Shed For Lease in Bilaspur Tauru
Premier destination for industrial sheds for rent in Bilaspur. Strategically located and equipped with modern infrastructure, these industrial sheds offer the perfect space for your business operations. With a focus on security, convenience, and providing you with flexible leasing options to suit your needs. Whether involved in manufacturing, warehousing, or other industrial activities, our spacious and versatile sheds are designed to optimize productivity.
Artistic
PEB & Civil Specification of Pragati Warehouse in Bilaspur Tauru
Lease Details of Pragati Warehouse Bilaspur Tauru
Get Lease Details of Industrial Shed for Lease in Bilaspur Tauru.
| Industrial Shed For Lease In Bilaspur Tauru | Industrial Shed For Lease (Price) |
| Industrial Shed in Bilaspur Tauru | Get Best Price |
Specification of Pragati Warehouse in Bilaspur Tauru
Dock Doors:
• 1 dock/8000 sq ft of Warehouse plinth. Sectional doors (with vision panels).
• 25% of docks with Levelers (6mt) + 25% of docks with Future Provision for Levelers
MHE Entry:
• 1 MHE entry for warehouse up to 2 lakh sq. ft. plinth area.
• 2 MHE entries for warehouse of more than 2 lakh sq. ft. plinth area
Canopy: 4.5m wide Canopy at 5m height from road level.
Plinth: Finished Floor Level of 1.2m.
Floor Loading: 7MT Puncture Load to enable racking & movement of material handling equipment. UDL is 6T/Sqm.
Floor Treatment: FM2 flooring with densification on Top surface.
Façade: Aesthetically Designed ACP Façade with UV Coated toughened glass.
Site Infra of Pragati Warehouse Bilaspur Tauru
Boundary Wall: 8 ft. high wall measured from the high side (50-75 mm pre-cast wall), with 600 mm diameter concertina wire on top.
Utility Buildings: Security Office, FMO office , Common Driver Room, Pump Room Transformer Yard & DG Yard .
STP: STP common for the park.
Roads: M40 -RCC Road with 40 MT Axial load for 250 trucks movement /day
Docking Apron: RCC -16.5m wide apron for loading/unloading enabling 40 ft. Truck Movement.
Truck Parking: M40, 80mm Pavers.
Car & Bike Parking: M30, 60mm Pavers.
Landscaping: Maintained as per Statutory Requirements with Lawns and Trees with irrigation system for every green area.
Pathway around Warehouse: 3m wide space on non-docking sides. This 3m includes - 1.8m wide paved area + 1.2m wide green area with irrigation system.
RWH Systems: Combination RWH pits & Pond, 50 years rainfall data considered & adequately designed as per the applicable building norms and local codes & 20 mins retention period
Industrial Shed For Lease in Bilaspur Tauru
Location Advantages Of Industrial Shed Bilaspur Tauru
- Excellent connectivity to Delhi International Airport, Delhi NCR, DLF Cybercity, IMT Manesar, Noida and GreaterNoida.
- Proximity to major Industrial hubs of Manesar, Bawal, Dharuhera, Bhiwadi, Jhajjar, Gurugram, Neemrana, Noida & Faridabad.
- Major Occupiers in vicinity include Amazon, Flipkart, Delhivery, Pepperfry, Usha, Apollo, Shadowfax, Ecom, Vmart Retail,Geodis, Lifestyle,Proconnect,Decathlon and others.
- Easy access to social infrastructure, viz., hospitals, schools, colleges, public transportation and residential catchments
